1/4 Scan 960*960mm P10 8000cd/㎡ Full Color Led Display

Place of Origin Shen zhen China
Marka adı AVOE LED
Sertifika CE RoHS
Model Number AE-P10OFRGB
Minimum Order Quantity 5sqm
Fiyat negotiable
Packaging Details Flight case, Plywood case.
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, Western Union, MoneyGram, L/C
Supply Ability 10K sqm per month

Ücretsiz numuneler ve kuponlar için bana ulaşın.

Whatsapp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

Eğer herhangi bir endişeniz varsa, 24 saat online yardım sağlıyoruz.

x
Ürün ayrıntıları
Name Fixed Full Color LED Display Resolution/mm 10mm
Pixel density/pixels/m² 10000/m² Module resolution 32*16
Scanning mode 1/4 scan Frame rate 60Hz
Vurgulamak

8000cd/㎡ Full Color Led Display

,

960*960mm Full Color Led Display

,

P10 Led Outdoor Display Board

Mesaj bırakın
Ürün Açıklaması

P10 outdoor full color led display For Shops 1/4 Scan 960*960mm Cabinet led outdoor display board



Features:

● RGB deep grey scale processing, rich color and HD image effect.



● Strong cabinet with reinforcing rib, tensile and quakeproof, with dissipation holes, lifespan more than 10 years.



● Energy saving design, can reduce 25% of consumption, it saves cost for customer, also friendly to the environment.



● Precision, Fast& flexible installation type, can be used in any installation conditions.



● High intensity& anti-aging material, protection level as high as IP65, can resist any bad environment.



● Support dot by dot correction, to make sure the consistency of color and brightness for one screen.



● High quality material, mature craftsmanship, large-scale manufacture and reliable quality.



● Professional navigation connector, keep the safety of whole screen.



Aplication:

Supermarkets, home, office, school, warehouse, shopping malls , hospitals ,production line , metro stations etc.





Parameters

Resolution/mm 10mm
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000/m²
Module resolution 32*16
Module size/mm 320*160
View distance 9-400m
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances CAT6 cable:<100 m; Single mode fiber:<10 km
Driving mode Constant driving current
Scanning mode 1/4 scan
Frame rate 60Hz
Refresh frequency >2880Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <900W
Average power:/㎡ <350W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment Windows (2007/XP/Vista/7/8/10)
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moisture-proof, dust-proof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Installation Procedure

1/4 Scan 960*960mm P10 8000cd/㎡ Full Color Led Display 0



1/4 Scan 960*960mm P10 8000cd/㎡ Full Color Led Display 11/4 Scan 960*960mm P10 8000cd/㎡ Full Color Led Display 21/4 Scan 960*960mm P10 8000cd/㎡ Full Color Led Display 3
